What the CZD-708D Cuts
According to the supplier description, the CZD-708D handles cotton, woolens, linen, silk, chemical fiber and leather. In practice that means it covers the everyday range of a garment cutting room, from lightweight shirting and lining fabrics through to heavier woolen coatings and leather work.
The specification table lists the application as light to medium-heavy material, which is a useful boundary. If your work is dominated by very dense or very thick spreads, confirm suitability with us before ordering rather than assuming the machine will handle it.
Key Features
The supplier description highlights several characteristics that matter in daily cutting room use:
- Lower noise — less operator fatigue over long shifts and a more comfortable working environment.
- Less temperature rise — the machine stays cooler in continuous operation, which is easier on the operator and on heat-sensitive fabrics.
- High power — the 1600 W motor drives the blade through demanding spreads.
- Less vibration — steadier cutting and better control along the marked line.
- Built-in auto-sharpening device — the blade is sharpened on the machine, keeping the cutting edge consistent without removing the blade for separate sharpening.
- Wide blade options — available in 8, 10, 12 and 13 inch sizes, so you can match blade length to your typical spread depth.
These are the supplier's stated characteristics. We present them as described rather than as independently measured figures.
Choosing Blade Size and Cutting Height
Two selections determine how well the CZD-708D fits your work: blade length and cutting height.
Blade size (8, 10, 12 or 13 inch) should follow the depth of your spreads. A shorter blade gives more control on shallow spreads and tighter curves; a longer blade lets you cut deeper lays without repositioning. If your cutting room runs a mix of spread depths, it is common to keep more than one blade length on hand.
Cutting height options are 110 / 160 / 210 / 260 / 285 mm. Choose according to the maximum ply height you actually cut, not the occasional peak. Running a machine well below its rated height is normal; consistently running at the limit is not.
If you are still deciding between machine types, our guide to straight knife vs round knife vs band knife cutters explains where each format fits, and the fabric cutting machines buyer selection guide walks through the wider selection process.
Specifications
| Item | CZD-708D |
|---|---|
| Application | Light to medium-heavy material |
| Power | 1600 W |
| Voltage | 220 V |
| Cutting height options | 110 / 160 / 210 / 260 / 285 mm |
| Max. speed | 4,500 rpm |
| Weight (N.W / G.W) | 18 / 20 kg |
Who It Suits
The CZD-708D is positioned for both large-scale garment factories and tailor shops. In a large factory it works as a production straight knife on light to medium-heavy spreads, with the servo drive and auto-sharpener supporting sustained use. In a tailor shop or sample room it offers the same cutting capability at a size and weight that suits a smaller bench and a single operator.
Because the machine covers a broad material range, its listed range spans several fabric types, so one machine can be specified for mixed fabric work across the week.
Safety and Maintenance Notes
General good practice for straight knife cutters applies to the CZD-708D:
- Keep the auto-sharpening device in working order and check the blade edge regularly; a dull blade forces the operator to push, which is where control is lost.
- Power down and isolate the machine before changing blades, cleaning the blade path or carrying out any adjustment.
- Keep hands and the feed path clear, and use a proper cutting table and straight edge rather than freehand guiding on deep spreads.
- Check the power supply matches the 220 V rating, and use appropriate earthing.
- Store and transport the machine carefully — at 18 kg net it is portable, but the blade must be protected.
- Follow the operator manual for lubrication and periodic checks; keep a spare blade and sharpening consumables on hand so a worn edge never becomes a reason to force a cut.
These are general notes, not a substitute for the machine's own manual and your site safety procedures.
Buyer Checklist
Before requesting a quotation, confirm the following:
- [ ] Materials you cut most often, and whether any fall outside light to medium-heavy.
- [ ] Maximum ply height you need, matched to one of the 110 / 160 / 210 / 260 / 285 mm cutting heights.
- [ ] Preferred blade size: 8, 10, 12 or 13 inch, and whether you need more than one.
- [ ] Voltage availability on site (the machine is rated 220 V).
- [ ] Whether you need spare blades and sharpening consumables included.
- [ ] Quantity required and any customization needs.
- [ ] Delivery destination, so logistics and transportation can be quoted.
Related Machines
The CZD-708D sits within our wider range of cloth cutting machines, alongside other cutting and finishing equipment. If your requirement is for a different format or capacity, tell us what you cut and we will point you to the right category.
Request a Quotation
Specifications, availability, MOQ and lead time are confirmed on quotation. Certificates available upon request. To discuss the CZD-708D for your cutting room, send your material list, ply heights and blade preference through our contact page and we will respond with a tailored quotation.
